Angular Contact Bearing B0808F7

HPDL-Type:Angular Contact Bearing B0808F7
ID:2"(50,8mm)
OD:2,5(63,5mm)
Querschnitt:0,25" x 0,25"(6,35mm x 6,35mm)
Dichtung:Open
Käfigewerkstoffe:Brass
Cr(N):1800
Ca(N):3510
Cor(N):4270
Coa(N):10140
Gewicht(Kg):0,045
Betriebstemperaturen:-53℃~+120℃

Produktbeschreibung

The same as standard angular contact bearings,  HPDL Angular Contact Bearing works well in radial or combined radial-thrust applications and it features a

circular pocket separator and a 30° contact angle. The chief benefit of this kind of bearing is that it offers greater thrust capacity than other two kinds of bearings. However the space will be more limited because this kind of bearings is usually designed in pairs.


Contact HPDL for more detials.
